Features
- Compact and lightweight
- Linear motion and Rotary motion available
- Split range available
- Easy calibration
- AUTO/MANUAL function
CP P/P Positioner
- Compact and lightweight
- Linear motion and Rotary motion available
- Split range available
- Easy calibration
- AUTO/MANUAL function
Specification
| Specs | Standard | Option |
| Input signal | 20～100kPa | |
| Supply air pressure | 0.14～0.7MPa | |
| Stroke / open angle | 12～50mm, 40～100mm／60～90° | |
| Air connection | Rc1/4 (圧力計Rc1/8) | NPT1/4 (圧力計1/8) |
| Pressure gauge | 0～0.2MPa 0～0.4MPa 0～1.0MPa | |
| Cam | Linear characteristics | Non-linear characteristics |
| Ambient temperature | -20～70℃ | Low temp.（L）－50～60℃ High temp.（H）0～100℃ |
| Material | Base: Aluminium Diecasting Cover: Aluminium Diecasting | |
| Weight | Approx. 1.4kgs |
| Specs | Performance | |
| Single acting | Double acting | |
| Linearity | ±2.0% | |
| Hysterisis | 1.0% | |
| Repeatability | 0.5% | |
| Sensitivity | 0.5% | |
| range of supply air puressure | 0.3％／0.01MPa | |
| posture torelance 10°／90° | 0.2％／4.0％ | |
| Resistance against vibration | 1%／1G | |
| Air consumption (Nl/min) | 5/0.14MPa | 11/0.4MPa |
| 出力圧力50%時 | ||
| Max Cv (Nl/min) | 60／0.14MPa | 140／0.4MPa |
| 出力側空気開放時 | ||
 |
Attention for usage of pneumatic instruments |
 |
* Clean and dry air (dew point -30 or below) is required. * Air filter 5μm or smaller is required. All specifications are subject to change without prior notice. All figures are effected by the valve/actuators. |
Where to look up the Serial No
We have a database, which can specify model from serial number. Please let us know the Serial Number written on the plate.
