MDS-2008DS Lab/Pharma Tablet Dissolution Tester Apparatus

Lab/Pharma Use Tablet Dissolution Tester Apparatus

Dissolution system Drug dissolution sampling system Dissolution method; compatible with basket method, paddle method, small cup method, paddle butterfly method and rotating drum method at the same time; Dissolution cup: 6/8 cup can be switched by software to realize isothermal rehydration Stirring shaft: segmented shaft design, only need to replace the basket (paddle) when switching the dissolution method, no need to manually re-adjust the height of the positioning basket (paddle), and quickly switch the dissolution method; only need to adjust the dissolution cup and sampling when switching the small cup method Needle is fine. Photosensitive lighting: with white light and red light illumination, three levels of brightness adjustable, turn off the ambient lighting when the photosensitive drug is dissolved, and turn on the red light. Dosing system: a single dosing system, which can realize simultaneous or sequential dosing, and the interval of sequential dosing can be set. Water bath system: square integrated sink with arc corners, easy to clean; bottom drain, which can be completely drained; ceramic heating tube heating, safe and reliable, and with over-temperature and water shortage alarms. Software system Drug dissolution sampling system, dissolution program: can store more than one hundred experimental programs, and can be imported and exported via USB, which is convenient for program export and import between instruments. Account: It can store 40 login accounts and passwords, which can be divided into three levels: administrator, advanced user, and operator. The operation authority can be controlled by levels; the administrator can assign and modify the account and password uniformly. Record: Built-in thermal printer, operation records and test data can be printed and saved by the printer; with log function, the instrument operation record can be stored in the storage device of the instrument along with the operation account and operation time, and can be audited and tracked. It can be encrypted and exported when necessary, and cannot be modified or deleted. Alarm system: power-on self-check, operation monitoring, fault diagnosis and isolation and alarm recording functions Reservation function: It can realize the reservation heating function. Basket (paddle) shaft
