SMART® Spectro 2 Spectrophotometer Order Code#: 2000-02

A spectrophotometer that is easy to use and more accurate than anything in its price range. With automatic wavelength selection, pre-programmed tests, and superior performance—this is the best spectrophotometer for the money!

Add to quote

Features

A spectrophotometer that is easy to use and more accurate than anything in its price range. With automatic wavelength selection, pre-programmed tests, and superior performance, this is the best spectrophotometer for the money!

Specifications


Wavelength Range:	350-1000 nm
Wavelength Accuracy:	±2 nm
Wavelength Resolution:	1 nm
Wavelength Bandwidth:	4 nm (max)
Photometric Range:	0-125%T, -0.3-2.500A
Photometric Accuracy:	±0.005A
Photometric Noise:	<0.001A at 0A; <0.002A at 2A
Photometric Stray Light:	=0.4 %T @360 nm
Dispersive Device:	Grating – based system
Optical Mount:	Modified Ebert
Grating:	1200 grooves/mm ruled grating
Display:	5.1 inches diagonal
Interface:	USB, Bluetooth® (mobile printer only Code 5-0066)
Light Source:	Quartz halogen
Sample Chambers:	25 mm round cell, 10 mm square cuvette UDV, COD
Detector:	Silicon photodiode
Temperature Range:	0-40°C
Modes:	Conc., %T, ABS
Pre-Programmed Tests:	Yes
Wavelength Selection:	Automatic
User Tests:	Up to 25 can be entered and edited
Datalogging:	USB, datalogs 500 tests
Diagnostics:	Yes
Power:	110/220 volt or battery pack (rechargeable)
Weight:	4.65 kgs (10.3 lbs)
Size:	35 cm x 28 cm x 17 cm

Accessories

Item Description	Order Code
Carrying Case	2000-CS
Battery Pack (rechargeable)	2000-BPC
Replacement sample cells (round)	0290-6
Cuvettes	29653-10
Bluetooth® Mobile Printer	5-0066
Syringe, UDV Blanks and Storage Bag Accessory Pack	1961
Pipettor, UDV Blanks, Storage Bag and Rack Accessory Pack	1962

SMART Spectro Colorimeter Reagent Listing

Test Factor	Test Method (# of reagents)	Range**	# of Tests	Ship Code	Order Code
Alkalinity UDV **	Unit Dose Vial (1)	15-200	100	NH	4318-J
Aluminum †R	Eriochrome Cyanine R (4)	0.01-0.30	50	NH	3641-01-SC
Ammonia Nitrogen †R (Fresh & Salt Water)	Salicylate (3)	0.02-1.00/ 0.10-1.00	25	LQ	3659-01-SC
Ammonia Nitrogen HR †R	Nesslerization (2)	0.05-4.00	50	R1	3642-SC
Barium	Barium Chloride (1)	—-	50	NH	3638-SC
Biguanide	Colorimetric (1)	5-70	50	NH	4044
Borate UDV**	Unit Dose Vial (1)	—-	100	NH	4322-J
Boron	Azomethine-H (2)	0.05-0.80	50	NH	4868-01
Bromine	DPD Liquid (3)	0.10-9.00	50	NH	4859
Bromine LR	DPD Tablets (3)	0.04-9.00	100	NH	3643-SC
Bromine UDV**	Unit Dose Vial DPD (1)	0.3-22.0	100	NH	4311-J
Cadmium	PAN (4)	0.02-1.00	50	R1	4017-01
Carbohydrazide	Iron Reduction (3)	0.005-0.900	100	R1	4857
Chloride TesTab	Argentometric (1)	0.5-30.0	50	NH	3693-SC
Chlorine (Free & Total)	DPD Tablets (3)	0.02-4.00	100	NH	3643-SC
Chlorine – Free UDV**	Unit Dose Vial (1)	0.10-10.00	100	NH	4311-J
Chlorine – Liquid DPD	DPD (3)	0.30-4.00	144	R1	4859
Chlorine – Total UDV†	Unit Dose Vial (1)	0.1-10.0	100	NH	4312-J
Chlorine Dioxide	DPD tablet/Glycine (2)	0.04-7.00	100	NH	3644-SC
Chromium (Hexavalent)	Diphenylcarbohydrazide (1)	0.01-1.00	100	HF	3645-SC
Chromium (Total, Hex & Trivalent)	Diphenylcarbohydrazide (5)	0.03-1.00	100	HF	3698-SC
Cobalt †R	PAN (3)	0.02-2.00	50	HF	4851-01
COD LR with Mercury *	Digestion (1)	7.5-150 mg/L	25	R1	0075-SC
COD LR without Mercury *	Digestion (1)	7.5-150 mg/L	25	R1	0072-SC
COD SR with Mercury*	Digestion (1)	50-1,500 mg/L	25	R1	0076-SC
COD SR without Mercury*	Digestion (1)	50-1,500 mg/L	25	R1	0073-SC
COD HR with Mercury* †R	Digestion (1)	500-15,000 mg/L	25	R1	0077-SC
COD HR without Mercury *	Digestion (1)	500-15,000 mg/L	25	R1	0074-SC
Color	Platinum Cobalt (0)	15-1,000 cu	∞	NH	NA
Copper BCA – LR	Bicinchoninic Acid (1)	0.05-3.50	50	NH	3640-SC
Copper – Cuprizone	Cuprizone (2)	0.01-2.00	50	R1	4023
Copper DDC †B	Diethyldithiocarbamate (1)	0.05-6.00	100	NH	3646-SC
Copper UDV†	Unit Dose Vial, Bicinchoninic acid (1)	0.2-4.0	100	NH	4314-J
Cyanide	Pyridine-Barbituric Acid (5)	0.05-0.50	50	R1	3660-01-SC
Cyanuric Acid	Melamine (1)	16-200	40	NH	3661-01-SC
Cyanuric Acid UDV**	Unit Dose Vial, Melamine (1)	5-150	100	NH	4313-J
DEHA	Iron Reduction (3)	0.005-0.700	100	R1	4857
Dissolved Oxygen (DO)	Winkler Colorimetric (3)	0.3-12.0	200	R1	3688-SC
Erythorbic Acid	Iron Reduction (3)	0.02-3.00	100	R1	4857
Fluoride †B	SPADNS (2)	0.1-2.0	50	R1	3647-02-SC
Hardness (Total) UDV**	Unit Dose Vial (1)	10-500	100	NH	4309-J
Hydrazine	P-dimethylaminobenzaldehyde (2)	0.010-0.750	50	NH	3656-01-SC
Hydrogen Peroxide LR	DPD (2)	0.02-1.50	100	NH	3662-SC
Hydrogen Peroxide HR	DPD (2)	1-60	100	NH	4045-01
Hydrogen Peroxide Shock	DPD (2)	4-225	100	LQ	4045-01

New tests are being developed for the SMART Spectro Colorimeter. Please contact our Technical Service Department for information regarding additions.

* Requires COD Adapter Code 5-0087 and Heater Block.

** As ppm except as otherwise indicated.

† Prop 65 – C: WARNING: Cancer – www.P65Warnings.ca.gov
R: WARNING: Reproductive Harm – www.P65Warnings.ca.gov
B: WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Ship Code

(NH) Non-Hazardous Material – No Fees Applicable.
(R1) Small Quantity Hazardous Material – No Fees Applicable.
(LQ) Hazardous Material – Air Fees Applicable.
(R2) Hazardous Material – Air Fees Applicable.
(R3) Hazardous Material – Air Fees Applicable.
(HF) Hazardous Material – Air and Ground Fees Applicable.

Digestion Tubes for Total Nitrogen and Total Phosphorus

Item Description	Range	Order Code
Low Total Phosphorus	0-3.5 mg/L	4024-01
High Total Phosphorus	0-100 mg/L	4025-01
Total Nitrogen	0-25 mg/L	4026-01

Multi-Range COD Reagent Systems

Item Description	Range	Order Code
Mercury-Based COD Reagent	0-150 ppm (EPA approved)	0075-SC
Mercury-Based COD Reagent	0-1500 ppm (EPA approved)	0076-SC
Mercury-Based COD Reagent	0-15,000 ppm	0077-SC
Mercury-Free COD Reagent	0-150 ppm	0072-SC
Mercury-Free COD Reagent	0-1500 ppm	0073-SC
Mercury-Free COD Reagent	0-15,000 ppm	0074-SC
